| Power |
| Output voltage regulation |
1% |
| Output power factor |
0.8 |
| Input power factor |
0.95 |
| Output power |
800 W |
| Input operation voltage (min) |
160 V |
| Input operation voltage (max) |
280 V |
| Output operation voltage (min) |
220 V |
| Output operation voltage (max) |
240 V |
| Surge energy rating |
600 J |
| Efficiency |
88% |
| Emergency Power Off (EPO) |
No |
| Output voltage Total Harmonic Distortion (THD) |
3% |
| Crest factor |
3:1 |
| Output power capacity |
1 kVA |
| ECO mode |
Yes |
| Ports & interfaces |
| Socket circuit breaker |
Yes |
| USB port |
Yes |
| Serial interface |
Yes |
| SmartSlot |
Yes |
| AC outlets quantity |
3 AC outlet(s) |
| AC outlet types |
C13 coupler |
| Power plug |
C14 coupler |
| Serial ports quantity |
1 |
| USB port type |
USB Type-B |
| Performance |
| Audible alarm modes |
Alarm when on battery, Fault, Low battery alarm, Overload alarm |
| UPS topology |
Double-conversion (Online) |
| Waveform |
Sine |
| Auto-restart |
Yes |
| Number of output phases |
1 |
| Number of input phases |
1 |
| LED indicators |
Yes |
| Noise level |
50 dB |
| Audible alarm(s) |
Yes |
| Maintenance-free |
Yes |
| Features |
| Output frequency |
50/60 Hz |
| Audible alarm modes |
Alarm when on battery, Fault, Low battery alarm, Overload alarm |
| UPS topology |
Double-conversion (Online) |
| Waveform |
Sine |
| Output voltage regulation |
1% |
| Auto-restart |
Yes |
| Number of output phases |
1 |
| Number of input phases |
1 |
| Output power factor |
0.8 |
| Input power factor |
0.95 |
| Output power |
800 W |
| Input operation voltage (min) |
160 V |
| Input operation voltage (max) |
280 V |
| Output operation voltage (min) |
220 V |
| Output operation voltage (max) |
240 V |
| Surge energy rating |
600 J |
| Efficiency |
88% |
| Emergency Power Off (EPO) |
No |
| Output voltage Total Harmonic Distortion (THD) |
3% |
| Noise level |
50 dB |
| Crest factor |
3:1 |
| Audible alarm(s) |
Yes |
| Output power capacity |
1 kVA |
| Socket circuit breaker |
Yes |
| ECO mode |
Yes |
| Maintenance-free |
Yes |
| Input frequency |
40/70 Hz |
| Battery |
| Battery technology |
Sealed Lead Acid (VRLA) |
| Battery recharge time |
4 h |
| Automatic battery test |
Yes |
| Design |
| Rack capacity |
2U |
| Form factor |
Rackmount |
| LED indicators |
Yes |
| Product colour |
Black |
| Certification |
CE, IEC 62040-1-1, IEC 62040-1-2 REACH |
| Display type |
LCD |
| Operational conditions |
| Operating temperature (T-T) |
0 – 40 °C |
| Storage temperature (T-T) |
-20 – 50 °C |
| Operating relative humidity (H-H) |
0 – 95% |
| Storage relative humidity (H-H) |
0 – 95% |
| Operating altitude |
0 – 3000 m |
| Non-operating altitude |
0 – 14763.6 m |
| Technical details |
| Output frequency |
50/60 Hz |
| Harmonized System (HS) code |
85078000 |
| Compliance certificates |
RoHS |
| Weight & dimensions |
| Package width |
455 mm |
| Package depth |
551 mm |
| Package height |
218 mm |
| Weight |
11 kg |
| Width |
437 mm |
| Package weight |
13.1 kg |
| Height |
86 mm |
| Depth |
312 mm |
| Packaging data |
| Cables included |
USB cable |
| Manual |
Yes |
| Software CD |
Yes |
| Package width |
455 mm |
| Package depth |
551 mm |
| Package height |
218 mm |
| Package weight |
13.1 kg |
| Logistics data |
| Harmonized System (HS) code |
85078000 |
| Certificates |
| Certification |
CE, IEC 62040-1-1, IEC 62040-1-2 REACH |
| Other features |
| Nominal output voltage |
230 V |
| Nominal input voltage |
230 V |
| Packaging content |
| Cables included |
USB cable |
| Manual |
Yes |
| Software CD |
Yes |
